Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System
Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System

大画像 :  Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System

商品の詳細:
Place of Origin: China
ブランド名: GreFlow Energy
証明: MSDS UN38.3
Model Number: 20kw lithium battery 20kwh lifepo4 battery
お支払配送条件:
Minimum Order Quantity: 2 packs
価格: inquiry us
Packaging Details: Standard Export UN Box
Delivery Time: 7-15 days
Payment Terms: T/T, L/C
Supply Ability: 200 per month
連絡先
詳細製品概要
Product name: 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System Battery Cell: LiFePo4 Prismatic battery cell
Dimension: 510*250*800MM Net Weight: 185kg
Weight with package: 185KG Cycle life: 6000 times at 80% DOD
Cell type: LiFePO4 3.2V 200Ah cell Communication protocolsion: CAN and RS485
Support Inverter: Sorlark, Deye and other most of inverter brands Extent: support 8pcs connection in parallels
Application: for home energy storage system

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 0
Descriptions of Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System


Technical specification
Battery Type LiFePo4 (Lithium Iron Phosphate Battery)
Norminal Voltage (V) 51.2V
Norminal Energy (KWh) 20.48KWH
Design Capacity 400Ah
Design Life 15 Years

Product Size
Size LWH; 510*250*800MM
Weight 185KG

Technical Parameters
Cycle life > 6000 times 80% DOD
Operating Voltage Range 40V- 58.4V
Charging Voltage DC 58.4V
Charging/Discharging Current (A) Same Port 100A
Internal Resistance <30mΩ

BMS Parameters
Self-Consumption <2W
Rated Voltage 51.2V
Balance Current 30-65 (mA)
Communication Method CAN / RS485 / RS232
Information Storage 500 Strip
Charging limiting Current can be set through upper computer

Ambient Temperature
Operating Temperature -10°C ~ 50°C
Storage Temperature 10°C ~ 50°C
Humidity 15% ~ 75%

Warranty
Warranty time 5 Years



Image display of 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 1

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 2Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 3



If you need inverter with our Power wall storage battery, we can supplyWall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 4



Compatible Inverter brands of Smart Energy Storage Off-Grid Solar Battery Storage

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 5

The Features of 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System

1. Smart. Each module is equipped with an independent BMS.
2. Easy installation. design simple bracket, just plug & play.
3. Safe. Apply for Lithium iron phosphate battery cell, no possibility to get fire.
4. Certifications. MSDS and UN38.3, CE and IEC in applying.
5. Modular. Modular expansion, support 8pcs connection in paralles.
6. Longer lifetime. 6000 cycles, 15 years design life.

max support 15pcs connection in parallels

Solution Diagram
Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 6

What is a solar battery and how does it work?
Solar panels make more electricity during the middle of the day than they do at any other time.
The middle of the day also happens to be when homes use the least amount of electricity. Because of this, your solar panels will produce a lot of electricity in the afternoon that you won’t need.

Solar batteries are able to store that extra solar energy so you can use it later on.
Solar powerwall batteries are able to store that extra solar energy so you can use it later on. This lets you power your home on clean renewable energy from your solar panels, even when they aren’t producing electricity.
What’s great about installing a solar powerwall battery is that it allows you to be less reliant on the grid while ensuring you have access to reliable backup power when there’s a power outage.
Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 7
Features of Wall Power Battery Replace Tesla Powerwall 10 KWH 2 Specs 48v 200ah Lithium Battery

Longer Cycle Life: Offers a significant longer cycle life and longer float/calendar life than lead acid batteries helping to minimize replacement cost and reduce total cost of ownership.
Higher Power:Delivers twice the power of lead acid batteries, even high discharge rate, while maintaining high energy capacity.
BMS Protection: Under/Over voltage and current protection ensuring safe and efficient operation.
Charging: Designed to work with AGM chargers.
Safety: Advanced LiFePO4 cell design includes various safeguards including high temp thermal fuse, flame retardant additive and pressure relief valves.
Increased Flexibility: Battery Specialist LiFePO4 batteries are a "drop-in replacement" of lead acid batteries.

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 8

The Package of wall mounted battery 48V 200Ah wall mount 10kwh powerwall battery
Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 9

We also have 30Kwh Wall standby energy storage battery for your choice

Inquiry our sales for details

Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 10

the Shipping Method



You can choose DHL, Fedex UPS to door if it is urgent

You can choose By sea to door for sample and not urgent

For batch order you can choose by sea to port

We have MSDS, UN38.3 test report for kinds shipping ways.



Wall Standby 20kw Lithium Battery 20kwh Lifepo4 Battery For Solar Energy System 11
